ABA | Original Worm Drive Hose Clip | 12mm Band Width | W4 304 Stainless Steel

ABA | Original Worm Drive Hose Clip | 12mm Band Width | W4 304 Stainless Steel

ABA-ORG-12-W4-24

81,33 Kč
81,33 Kč
Sale Sold out
Shipping calculated at checkout.

Out of stock
  • Free standard shipping. Next day delivery available. Find out more
View full details

Need advice? Talk to our expert customer support team

Call

TBC
Monday-Friday 8am to 4pm

Email

sales@hcl-clamping.eu
Scroll
Clamp Dia mm ?

Clamp Dia mm: The required metric size for a secure fit, indicating the outer diameter (in mm) of the component the clamp is meant to hold.
Clamp Dia In ?

Clamp Dia In: The minimum to maximum inner diameter (in.) the clamp can securely cover, defining its usable size range.
Band Width ?

Band Width: The measurement of the clamp's band or strap, indicating its width (often in mm or inches) and how much surface area it covers.
HCL P/N ?

HCL/ PN: The unique identifying number assigned to a part by HCL
MFG P/N ?

MFG P/N: The unique identifying number assigned to a part by its manufacturer.
Corrosion Res ?

Corrosion Resistance: Refers to a material's ability to resist deterioration or damage caused by chemical reactions with its environment, such as rusting.
Price ?

Price: The cost per unit

Stock ?

Stock: available products that can be purchased

Order Qty ?

Order Quantity: The total amount of units you wish to order

15.0mm - 24.0mm - 0.59in - 0.94in - 12.0mm (0.47in) - ABA-ORG-12-W4-24 - 0813 4003 020 - Very Good - 81,33 Kč 0
19.0mm - 28.0mm - 0.75in - 1.10in - 12.0mm (0.47in) - ABA-ORG-12-W4-28 - 0813 4003 024 - Very Good - 82,07 Kč 0
22.0mm - 32.0mm - 0.87in - 1.26in - 12.0mm (0.47in) - ABA-ORG-12-W4-32 - 0813 4003 027 - Very Good - 83,56 Kč 0
26.0mm - 38.0mm - 1.02in - 1.50in - 12.0mm (0.47in) - ABA-ORG-12-W4-38 - 0813 4003 032 - Very Good - 84,55 Kč 0
32.0mm - 44.0mm - 1.26in - 1.73in - 12.0mm (0.47in) - ABA-ORG-12-W4-44 - 0813 4003 038 - Very Good - 91,25 Kč 0
38.0mm - 50.0mm - 1.50in - 1.97in - 12.0mm (0.47in) - ABA-ORG-12-W4-50 - 0813 4003 044 - Very Good - 92,98 Kč 0
44.0mm - 56.0mm - 1.73in - 2.20in - 12.0mm (0.47in) - ABA-ORG-12-W4-56 - 0813 4003 050 - Very Good - 104,89 Kč 0
50.0mm - 65.0mm - 1.97in - 2.56in - 12.0mm (0.47in) - ABA-ORG-12-W4-65 - 0813 4003 058 - Very Good - 112,82 Kč 0
58.0mm - 75.0mm - 2.28in - 2.95in - 12.0mm (0.47in) - ABA-ORG-12-W4-75 - 0813 4003 067 - Very Good - 115,30 Kč 0
68.0mm - 85.0mm - 2.68in - 3.35in - 12.0mm (0.47in) - ABA-ORG-12-W4-85 - 0813 4003 077 - Very Good - 123,24 Kč 0
77.0mm - 95.0mm - 3.03in - 3.74in - 12.0mm (0.47in) - ABA-ORG-12-W4-95 - 0813 4003 086 - Very Good - 137,86 Kč 0

Description

ABA Original clamps feature an extra strong one-piece pressed housing, rolled-up band edges and a smooth band underside that protects the hose. ABA Original – the trouble-free clamp with high tightening force and high breaking torque.

ABA Original Stainless S40
• All parts are made of SS 2333/AISI 304 stainless steel

Advantages at a glance
• High clamping force
• High break torque
• Protection of the hose thanks to the smooth band underside
• Every clamp is date stamped for traceability

Product Specification Sheet

Download

Specification

Manufactured By ABA
HCL P/N ABA-ORG-12-W4-X
Series ABA Original W4
Corrosion Resistance Very Good
Hose Clamp Width mm/in 12.0mm (0.47in)
Band Style Embossed Band
Band Material W4 304 Stainless Steel
Bolt/Screw Type Slotted Hex
Bolt/Screw Material W4 304 Stainless Steel
Bolt/Screw Size 7.0mm (0.28in) A/F
Finish Stainless Steel
Colour Silver
Country of Manufacture Sweden
Tariff Code 7326 90 92
Hazardous Goods No
RoHS Compliant Yes
